DM Photonics not offer only touch panels, but also provide complete projected capacitive (PCAP) solutions. From size selection and structural design to controller pairing and software support, every detail is carefully considered to create the best touch experience that perfectly meet every customers needs.

We are able to provide:

✔ Complete projected capacitive touch solution, including touch panels, touch controllers, firmware and software.

✔ Standard projected capacitive touch panels with sizes ranging from 0.96 inches to 32 inches.

✔ Glass-Film-Film (G+F+F) / Glass-Glass (G+G) structural design, allows for flexible design of different upper glass layers.

✔ Projected capacitive touch controllers are available with touch control panels or COF (chip on flex).

✔ Multi-finger operation is supported.

✔ Customizable cover glass designs.

Glove handling is supported.

Rubber gloves, cotton gloves, work gloves, and medical gloves are all supported.
Thicker gloves or gloves with special coatings can also be customized.

Anti-interference

IEC 61000-4-2 : Electrostatic Discharge Level 4, class B
IEC 61000-4-3 : Radiated Susceptibility Level III 10 V/m, criteria A
IEC 61000-4-6 : Conducted Susceptibility Level III 15 Vrms, criteria A
IEC EN60601-1-2 RS (Radiated Sus0ceptibility) 9 ~ 28V/m, Class A

Impact resistance

Supports glass cover panels up to 10mm thick.
Boosts signal strength, maintaining normal operation even on thick glass.

Waterproofing

When a small amount of water is on the touch panel surface, the touch panel can operate normally in the water-free area.
When a large amount of water is detected, the touch function can be automatically turned off.
Automatically resume normal operation after the water on the touch panel surface is wiped dry.
The glass cover frame can be added with waterproof button function.

We understand that every customer's needs are unique, so we offer a variety of value-added features, such as infrared resistance, waterproof buttons, and corrosion resistance, to help you create a touch solution that truly meets your application environment.

DM Photonics provides customized projected capacitive touch panel solutions with a variety of value-added options:

✔ Anti-IR: Blocks outdoor infrared radiation, preventing internal system temperatures from overheating and reducing the system's temperature by approximately 6°C.

✔ EMI Shielding: Protects against electromagnetic interference, meeting IEC61000 and DO-160 testing standards.

✔ Anti-corrosive: Corrosive gases are present outdoors and in some industrial environments; this corrosion-resistant design prevents functional loss.

✔ Aqua Switch: Projected capacitive waterproof switches prevent malfunctions when sprayed with water.

✔ Heater: Provides product heating and defogging.

✔ Glass Finish: Glossy, Anti-glare (AG), Anti-reflective (AR), Vi-K (Vi-K), Anti-ESD (Anti-Electrostatic Discharge) coating.

✔ All-Black: A color difference of ΔE ≤ 1 between the LCD display and the touchscreen frame.

DM Photonics PCAP is widely used in various markets. They can be used in smart home, industry, banking, outdoor commercial display, education, medical care, smart mirrors, games, military, marine, transportation (cars, airports, railway stations, subway stations, bus stations), special missions and other fields.

Standard Package

The touch panel packing with foam plastic materials

Packing with carton or wooden box

Delivery

Express: DHL, UPS, EMS, TNT, Fedex
Other: Air or sea transportation

Note:
Unpack the carton with the printed red arrow pointing up.
Hold a touch panel body instead of the FPC/COF all the time.
Avoid that the surface of the sensor glass is polluted after removing the protect film when assembly.
